Kitchen Furniture, Wooden Handles, Wedding Signs and Passive Amplifiers.

Its been a kind of on-off month in the workshop with it being summer. Although looking at the photos below its been a reasonably productive August.

We’re still working our way through the last few pieces for a client we’ve been working with for the last year. Now focused on his kitchen the guys I share the workshop with needed to build a large bench and table. The bench was in the style of a church pew with an oak frame that continued the theme that we’ve had throughout with quilted walnut panels added for contrast. For the frame I collaborated with one of the guys who is an old school woodworker and made up a few of the pieces of curved joinery for him. I think he was suspicious to start with of whether I’d be any use but it worked out well. The parts he made by hand were spot-on to the pieces I cut on the CNC. In the first three photos below you can see some of the pieces of the frame I cut and them being assembled. The fourth photo shows some of the large walnut panels being quilted with a point-roundover tool on the CNC and then the rest of this group of photos show the finished bench, a door frame we made for the same room and also a chest that will also go in the kitchen. This design combination looks really good and matched well with the brass screens in the kitchen doors that you’ll see further down the page.

The table for this customer was an interesting design with a stepped base. I cut a set of MDF panels from Tom’s design that they could use on the router and spindle moulder to make the 20 levels that make up the base. You can see these in the first photo below, in the second photo you can see the finished table which looked great. Unfortunately the customer decided he did not want the stepped look and that he wanted it smoothed out, doh. So in the third picture you can see the corners being hand-ground off. As of typing this is still a work in progress - we’ll also be cutting a kind of valley shape in the top of the table and filling it with epoxy. More of that next month…

Below are a few other pieces from the same kitchen. The arched frame will tuck into an alcove with the chest from the first section of photos at its base. On these it was nice to cut both the decoration, shape and also some half-lap joints for accurate assembly. The second set of three photos show the final finished version of the kitchen cabinet doors that have been a work in progress for months - here you can see the antiqued brass mesh in the background, this matches the quilted walnut panels really well. In the last photo you can also see the walnut trefoil added at the top of the lower arch part. These are really very beautiful now and have got to be some of the most ornate kitchen cabinet doors in existence…

It was initially planned to order metal handles for the doors above that would have a pyramid texture. These proved to be extremely expensive though, so I was asked if I might be able to make something similar in walnut. This was an interesting challenge as the texture is on 3 sides of a square cross-section. After a bit of playing around I decided to carve the sides of the handles with standard 2-sided machining then use the “legs” to position it for machining the top side. This last step required me to carve rectangles into a sheet of MDF on the table and inserting them, then zeroing of the top face and machining the third set of pyramids. In the first three photos below you can see each side being machined in the same order they were cut in. Once I’d perfected the prototype (this took three goes with customer input on design). It was time to start production - the final two photos show a set of nine handles being machined from one side and then the tops being cut. I have some longer versions to make next week to create the complete set. I was very happy with how these turned out. They’ll need to have threaded sleeves glued into the legs for installation, plus a reasonable amount of sanding still to go…

Finally, I had a couple of personal projects this month, in the first photo you can see a wedding post-box front I made for one of the guys in the workshop. Working to their design this was pretty straightforward v-carve and cutouts. The second and third images show a passive amplifier I made for my phone - this is a prototype but worked very well. I’ll tweak the design a little though and aim to make a finished version soon.

Cherubs, Textures, a Chimp and a Plaster Cast Test

The last 6 weeks have been fairly quiet in the workshop but I’ve still been ticking over with carving parts for clients and also used the spare time to start experimenting with some new ideas and techniques.

One thing I have been continuing to make are the Cherubs faces that are going to be installed in a clients library. Below you can see some of these in progress and the finished parts filling the third photo. In total there were 82 to make, suffice to say I’d seen enough of them by the time they were all cut and sanded…

We’re getting ever closer to finishing up with another clients work and I carved a few more pieces for that in anticipation of a big August push to get all the individual pieces finished and installed. Below you can see some light pattresses in the first photo and then an extra large version of the quilted walnut panels that we’ve made in the past to infill the posts in this clients kitchen. This wider version will be going over a door to complete the frame for the entryway. I’m really looking forward to this project being complete and the chance to get over to the house to take some final photos of all the eclectic mix of work we’ve done there.

One of the pieces of R&D I’ve been doing this month are some test cuts for textured door panels. The design for these is by my friend Joe Valasek in Oregon who has a business called Carveture making custom carved parts in the US. He had a client in the UK contact him about possibly doing some work for them so we’ve been running some tests and seeing how these might work if I were to make them. In the photos below you can see them being cut on the machine and the final panels (unsanded and unfinished). We’ll see whether this progresses into any work but its been interesting to work on and developing my own textured panel set is on my list of objectives for the year.

As a personal project I made myself a Chimp to go on my bedside table. This is based on the artwork from the book “The Chimp Paradox” by Prof. Steve Peters. I’ve found this book and the ideas in it extremely helpful to me in the last few years to help me calm my overactive brain and lead a more healthy and fulfilling life. The Chimp is designed as a daily reminder to keep up the good work. In terms of the object itself I used a thick Maple off-cut from a previous project, masked the face and then once it was cut I painted the areas I’d machined. When you peel the mask off it leaves nice clean lines for the paint and just needs some gentle sanding to finish. You can see the progress of the project in the photos below.

I’ve also been doing some R&D work to learn how to make a plaster cast from an original. For some clients who do not want finished parts in wood but who are looking for painted ornamental ceiling or wall decoration this will be a more efficient way to make detailed components than individually carving each one.

In this case I modelled a rosette and machined this using a very small tool to get a really good level of detail and finish on the part. You can see that in the first image below. This was lightly sanded and lacquered to give a good surface finish and ensure the mould material would not stick to the grain. I then cut a simple round shape to make the mould out of some scrap wood. The original was hot-glued into the mould - although in hindsight I should have been a bit more careful with this as there were some small gaps underneath it. I then put petroleum jelly around the edges of the mould to help with release once it was set. The 2-part silicon mould material was mixed and then poured over the master as you can see in the third and fourth photos below. I left this overnight to cure - then peeled it out. The original part did come with it as some of the material had got underneath, as you can see in the fifth photo, this was easy to remove though which left me with a good mould that I just needed to trim some of the flashing off. Finally I mixed some fine casting plaster and poured it into the mould leaving it for an hour to set before removing the finished part. In the final photo below you can see the original, the mould and cast piece all lined up. I was very pleased with the outcome and will continue my testing with some other designs to fully explore this new capability for the business.

Sacks, Chests, Jigsaw Frames, Kitchen Cabinets, Stair Carvings, Cherubs, my work continues to be varied...

Much has been going on both in the workshop and out of it for the last couple of months. Lots of good collaboration with the guys at Thomas Philpott Cabinet Makers ( who I share the workshop with and some interesting work of my own.

First up is a project for my daughters bedroom, she asked me to make a set of plywood shelves to go in the corner of her room, next to an existing set of shelves. I decided to make these as a set of boxes that would stack on top of each other, both to create an interesting non-uniform layout and so that I could still fit the pieces I needed to cut on my machine. In the three pictures below you can see how these were cut, assembled and then finally situated and in use. The parts for these were cut out of two standard sizes sheets of 12mm plywood.

Something I referenced in my last update is a sculpture I’m currently working on. This has moved on slowly but surely with a lot of hand-shaping as you can see in the first two images below and many hours of hand-sanding to get it to a beautifully smooth finish. I have now started to french polish this and will add a rope around its neck to complete it hopefully in the next week.

One of Tom’s clients asked him to make some chests to go onto their barge, he asked me to carve a shallow curve into the top of these. Below you can see in the images that I cut these both out of single quite large (for the CNC) piece of glued up Sapele. In the last image you can see them with a single coat of oil (and some settled dust) waiting for subsequent coats of finish.

Another job previously referenced in this journal was a set of jig-saw puzzle frames, made for an artist to create a unique way to show their work. These were cut from 25mm MDF and then sealed and sprayed to give a smooth white finish. You can see these individually and then assembled in the images below.

Last year I cut a number of pieces for a Gothic inspired kitchen we’re collaborating on, these then had to be stored away as the client wanted a number of others things doing for his house and the kitchen to be done last. I’m please to say we’re finally back to working on the kitchen, so I’ve been pulling out the previously cut parts and trying to remember how I made things and how they were intended to be put together. The first of these were the pillars you can see below. These are 80mm square section solid white oak with walnut inlays for the quilted sections and the shallow pyramids. For some of these I had to cut a side inlay as well as the front, you can see in the second image below the delicate operation to do this that requires 3 setups due to the length of the components. In the last image you can see how good these look finished and with a coat of oil. I’m really looking forward to seeing the whole kitchen installed.

The cabinet doors shown below are another part of the same kitchen. These are quite complex assemblies with 6 CNC cut parts and then a number of other components to finish them. The part I most like on these is an overlapping arch, to make the design work I designed a nice joint to allow them to slot together and still have the decorative grooves running through them to house a walnut bead. In the first 6 pictures below you can see how these were cut, how they go together and then the initial assembly. The way this joint worked with minimal hand fitting was extremely satisfying, especially as I designed these months ago and had to rely on the fact I’d done it correctly… In the last 3 pictures in the block below, you can see the parts for the lower section of the interior of the doors and single and double door partly assembled. The moulding in this part of the door will also have a walnut trefoil shape added at its point then everything in the frame will be backed with a brass mesh to complete it. They are going to look amazing.

The guys have also started work on a major renovation for another client. The first part of this that I got involved with were the stairs. For the newel posts and spindles Tom wanted 90 degree v-grooves cut on all four sides. The newels would have been unwieldy to get on the CNC machine to setup accurately and to also support them, so I made an MDF jig that could be used to hand-route these into each side. You can see this in use and the result of this operation in the first 3 images below. The pointed end of the newel was shaped with hand tools not on the CNC. The second three image below show the spindles. These were done on the CNC using an MDF jig with a stop to line them up and a piece to clamp 10 spindles at a time in place. Once secure I cut straight grooves across them,released them, rotated each 90 degrees and repeated. This worked really well with a set of ten taking around 40 minutes to cut.

Another part of the same staircase were some carvings to replicate a piece of decoration from an existing set of stairs in the same building. In the first picture below you can see the original at the top and my first test carving. Once we were happy with how that looked I made edits to the layout so that for each of the stair treads we had a coherent design based on the original that fitted its length, rather than just have it short or chop it short. This is a real benefit of using CAD/CAM to make something bespoke, that the model can be adjusted and re-worked before carving. In the rest of the images in the block below you can see the carvings being finished, assembled and oiled on the already built stair components. These have been installed now and I’ll look to get a photo for my next update.

In my last update I showed images of some decoration we’d created using a cherub head, again based on an existing carving. This is now being re-purposed to add decoration to some square blocks in the library Tom previously built for the client. To make the head fit the square shape and make sense I created a feather pattern and added a chamfered edge. Below you can see the two prototypes being cut and the results with a single coat of oil in context sat on a block the size of the ones they’ll be attached to.

Finally for this workshop update a few random items that do not really group together that I’ve made within the last couple of months. The first image is an Iroko sign for one of Tom’s customers. The second image are two of around twelve panels I made to match existing ones that decorate the window frames on the front of a clients house. The third image is 20m of Egg & Dart moulding stacked up in bundles that will become door frames for the interior of a customers fireplaces at some point in the future. The fourth image is a really nice texture cut with a 1” ballnose that will be the centre of a table (topped with glass). The fifth is the platform number from Harry Potter cut in stone coloured Corian and painted for my daughter. Lastly is a small carving I made as a gift for the incredible illustrator Chris Riddell ( who we saw at the Hay Literary Festival last month. This is based on his own image of himself from the Art Matters book he illustrated, I love this book and use it to reset my mental state when I start to mistakenly think I want a normal job again… Until next time.

All the things I've made so far in 2019...

I’ve made a poor effort with writing my journal this year although I have been quite busy, so here is a bumper update with the first three months highlights from the workshop.

I’m pleased to now be working with a gallery in the Cotswolds to show some of my artwork and bowls. One of these pieces is an oversized ash wood ring-pull (old style from when they used to come off completely) mounted on limed oak veneered MDF and framed with red-stained oak. This piece is entitled “Pop Art No.1.” - it plays around with the idea of the original pop art movement to elevate mundane objects and put them in unfamiliar context. The wood and size of the piece jars with expectations and it appears to float above the background. Below in the images you can see the parts being cut and then a couple of different angles of the finished piece which creates great depth with shadows.

Another piece is my interpretation of the shape created when starlings flock, this incredible visual spectacle is known as a murmuration. The forms and movement created by the undulating mass of birds is mesmerising. Murmuration No.1 is a solid black walnut carving cut from both sides and finished with Danish oil to enhance the grain pattern and allow it to interact with the changes in shape. I sculpted the main form in the software and carved this on the CNC before significant hand-finishing to accentuate the curves and get it as smooth as possible.

As well as the wall art I’ve also been making more bowls and finishing some of my older designs which are also being shown in the gallery. You can see see a selection of them in the first image below. The second and third image show some of the quicker jobs I’ve been doing in the workshop for the guys I share the space with. I make a lot of these square pyramid screw hole covers shown in the middle image, these ones are oak into walnut. I also often make fluted columns and the pyramids to decorate the top of them as shown in the third image below - this is partially finished limed oak.

Occasionally I like to try and make something for myself. Below is my interpretation of the cover of the King Crimson album, “In the court of the Crimson King”. This is one of my favourite album covers of all time, the original is based on a painting by Barry Godber that represents the Schizoid Man. It captures human angst in a way that really resonates with me, that seems just as apt in today’s world as it was 50 years ago when it was released.

I used this to test an idea I had about framing a deep carving in the same way a raised panel door is constructed. In this case I machined the maple for the main carving so it had a lip on it. The sapele frame was then made on the spindle moulder in the workshop with an angle on the top along with a rebate for the lip to locate into. Below you can see the maple being carved, then the frame being glued on to the carving and finally the finished oiled piece. I am really pleased with how the frame seems to be trapping the face to add even more drama and the angle on the top along with the corners leads your eyes into the middle. This assembly method holds the carving really well and keeps everything from curving.

The images below show a work in progress entitled “Bag of Sand”. This is an exploration to help me explore what gives a piece of art value, is it the idea, technical skill, craftsmanship, context, materials or is down to marketing and recognition. This is part of an ongoing set of work I’m creating with a working title of “Finding Truth in Absurdity”.

As well as my own work and the smaller jobs for the guys in the workshop I’ve also been working on some interesting client commissions this year. One of our customers is very interesting in carved cherubs and has a few 17th century examples that he wants to use in other work around his house. I spent quite a lot of time trying to capture the likeness of a pair of the carvings he already owns and went through 6 iterations before I was happy with them. You can see some of this work in the first row of photos below, in the middle one you can see the original cherubs (outer) in comparison with my third iteration (inner). Once I’d finally perfected the design, the first actual use was to edit it to create a version to add decoration to some wardrobe doors previously made by Thomas Philpott (who I share the workshop with). I had to flatten the features to fit into 22mm thickness and rebate the back so they would lay over the existing woodwork. You can see how these turned out in the second row of photos which shows them installed on a few of the doors.

For another client we’ve had an interesting variety of things to design and build for their house renovation. One of these was to create a decorative ring to surround a hole that goes from the ground floor to cellar. Guidance for this was the suggestion of roses and art-nouveau.. I designed a motif that we could cut into one eighth of the circle, creating the v-inlay of oak into walnut and then the guys could assemble and install these pieces into the full circle mounting it onto a lip that will hold a piece of glass to cover the hole.

Another project for this client was a book-case and decorative interior panel to go under the stairs. The decorative panel needed to contain glass and suggest a banister shape that would then be echoed on the wall behind it, with the steps leading down to the cellar. Tom and I collaborated on a design that would soften the sharpness of the stairs with some fluid curves and included some very large pieces of walnut to create an amazing end to the banister shape. Below you can see the progress of cutting the large piece of walnut (two sides to rebate the back to attach to the frame). The first picture on the second row of photos shows the oak frame components, which I also cut on the CNC, being assembled. These had some interesting butterfly joints and rebates cut into them for the glass. For such a big piece where I had to cut almost everything in multiple setups on the machine it went together really well. In the last image on the second row you can see the finished bookshelf and the decorative panel just after installation.

The banister for the cellar steps was made to echo the shape on the decorative panel, this needed to curve out from the wall and then come up at the bottom with a similar shaped end. The supports needed to look like stylised tree branches and also accommodate lights that were already installed in the wall. It was intended that it would be painted so it was made with poplar, subsequently the client decided that he wanted the banister dark to match the walnut, but not stained, so Tom had the good idea to have it upholstered with textured brown leather which looks and feels amazing. Here you can see some close-ups of it in the workshop waiting to go for installation.

The same client is also an artist and commissioned us to make a frame for 11 of his painting that would slot together like a jigsaw. This is still a work in progress but you can see the pieces as I carved them on the CNC and slotted together waiting for assembly, priming and painting. This is 4m x 2m - so is going to need a big wall to be displayed on…

Finally for this entry some parts that I cut in October last year we’re finished and installed this week. I’d carved 120+ arched pieces that had a 4mm wide walnut bead glued into the centre and then were cut to size using a jig I made to ensure the four corners would be correct to assemble them onto the side of the 6m long beams to make arches. In the top row of the photos below you can see this jig in action. This worked really well to quickly size all these parts and get nice sharp corners onto them for easy assembly. The picture at the start of the second row shows all the egg and dart I’d machined assembled into a moulding and then the final two images show the installed beams, including the base piece that i had also carved last year. The client was very happy with all the work we’ve done for him so far. Next we’re going to be finally getting to his kitchen which is going in the same room as the beams and should be equally as striking.

A lot more flower lights, some door embellishment and more wooden bowls.

Its been a relatively quiet few weeks in the workshop but I have been working on a few interesting things…

In the last blog entry I discussed a prototype I made for a ceiling light in the shape of a flower. The client was happy with the design so I went ahead and made 56 of them. You can see the photos of them in progress below with the backs being cut first then the front with the flower shape. The next two photos show them as they were being sanded and the fifth image shows the first few being installed into the decorative ceiling. I’ll try to get a better photo when they are completed. The final image in the set below has four views of a much larger version that I was also asked to make that will hold the sensor to automatically switch these lights on when someone comes into the room.

The guys who I share the workshop with had a job to take some doors they previously made for a client and add decorative beading to them. In addition they wanted to incorporate some small embellishments to add decoration. They asked me to cut some small winglets and pyramids that they could apply to the doors in contrasting woods. You can see these in the walnut they were cut from in the first two images below and then a shot of the doors themselves with the parts sitting in place. For such small pieces they really added to what are already very interesting doors.

In the last post I showed some new versions of my “Pear Chair” bowl that I’d made. Below you can see one of these with the oil applied. With all the curves it really shows the grain very nicely, even in this Sapele. I also have included a photo of a pear resting comfortably in the bowl for scale.

Continuing on the bowl theme I made a new set of prototype designs for some other ideas. These were cut into Ash as I thought the shapes would work really well with the strong contrasting grain of the wood. There are three very different designs. The smooth one is intended to resemble a bean, the polygonal one was inspired by some Japanese vases that I saw and the third is a sculpted whirlpool type shape. Each of these has produced something interesting and as always provided me with more to contemplate. I really like the way the smooth one looks and feels and also the sculpted part of the whirlpool shape and how it intersects with the grain pattern. The polygonal one had elements that were pleasing but was a bit underwhelming overall and some aspects of the shape just didn’t feel quite right. To try to better highlight where the dish part starts I thought I would pyrograph an effect of black liquid dripping inside the rim. I am intrigued by how this has changed its look and will be exploring the use of pyrography more with future designs. I also believe once this is oiled it will look very effective. Below in the first three images you can see all threel being cut on the CNC, the back first then material flipped over to cut the front. The second set of images shows them mostly sanded but not yet oiled, the light is placed to show the shape of each bowl more clearly. In the new year I will be continuing to explore what it is possible to do with wooden bowl shape and texture. Until then I wish anyone reading this a restful holiday and positive 2019.

Bits & Pieces, Flower Lights, New Iterations, Tardis Tiles, A Pear Chair and an Ash Stool.

From unconventional wooden bowls to my interpretation of a wooden stool I’ve covered a lot of ground again in the workshop in the last two weeks.

If your a regular reader of this journal you’ll know I’ve been making a selection of eclectic pieces for a client of the guys I share the workshop with (Thomas Philpott Cabinet Makers). I was at the clients house this week to take some measurements and took the opportunity to snap a few pictures. Below you can see (in order) the large walnut/oak Celtic knot inlay, the ceiling rose for the 20 light cords I made, the card-suit screw hole plugs and then three photos of the door stop flower carvings. The last photo in this group also shows a large walnut peg which goes between the skirting and the door frame that I carved. Not all of this is finished but it was interesting to see most things in place. The client is happy too which is good…

The same client has an arched hall ceiling which has a grid of moulding across it that requires a small light within each square. I was tasked with making something that would hold the LED light, had the shape of a flower and curved away from the ceiling. Below you can see the prototype for this. Its about 60mm across the petals (just over 2.25”) and 35mm deep (approx 1.5”). There are a couple of things to tweak if I this is approved and I do end up making the 55 that would be required to fill the space…

I’ve also been continuing to develop products for sale and experiment with my own ideas in the last fortnight. Below in the first three pictures you can see the latest incarnation of the standard magnetic beer cap catcher. This is cut in Ash wood. I used mask to help minimise the sanding required after the paint. You can also see I used my new logo branding iron to mark the backs.

In the fourth image you can see a new iteration of my magnetic key-holder. I changed the shape to an octogon and switched back to maple as the oak one I experimented with did not show the rippled shape well.

The fifth picture shows some prototype meat carving boards. In each of these the grooves are sloped to allow juices to run down into the circular well. This can then be poured off for making sauce etc. These turned out well and I now need to oil them and test them all to see which works best and also decide on my favourite designs. These heavily used the 2D toolpaths and fluting to achieve the slopes and carve the wells.

Lastly in this section you can see a project I did to experiment with some repeating tiles. The design for these closely resembles the walls in the current Tardis from the new TV series of Dr. Who. They did take a while to machine but look very effective and I learned a lot as their design is quite tricky to model and machine.

Another of my own projects I’ve been developing further is something I originally called the pot-belly bowl, after I posted a picture of it on Twitter a reply from @Scottran means I’m now dubbing it the “Pear Chair - A single fruit bowl”- thanks for the suggestion…

You can see from the first image why it was given this name. I love the shape of this but wanted to make it a bit bigger (perhaps to accommodate a pineapple or banana), shape-wise I also wanted to slope the corners down. These also allowed me to try some different parameters for the machining to create a ridged finish on the bottom. I found a large chunk of scrap Sapele in the workshop that was perfect for cutting a new batch (it was a big piece of scrap). You can see the progression of this below, first cutting the backs with the legs, then the fronts. The fifth and sixth image show a close up of the most ridged version and then all four of them with a single coat of oil. I love the look and feel of these bowls and how unconventional they appear. They are almost impossibly thin and can easily bend and flex - although its not really advisable if you don’t want it to snap. This batch will be finished now and then they’ll go on sale. The original has been taken home.

Last thing in this update is a stool I made for my son to go with the desk I built for him. I saw a design on the Open Desk website in a blog post that I thought was a good design and would suit his needs. I did not follow their design but instead developed my own to suit and cut it in solid Ash for looks and also to give me enough depth to put a curve in the top for comfort. It went together perfectly after machining although I did manged to snap the ring when clamping for glue. As a clean break it was easy to repair invisibly but I would adjust the design to probably make it thicker for more strength if I made another. I deliberately curved all the corners on the joints both to make them easier to cut, less likely to tear-out when cutting and also as a design feature. I think this is a good idea for CNC jointed furniture. I was very pleased with the finished object, it is comfortable and my son is happy which is most crucial element of all…

Pot Belly Bowl, Flowers, Card Suits, Light Rose, Door Head Fan and Celtic Weave Inlay.

There has been a lot of different things going through the workshop in the last couple of weeks. To start this journal entry though I’ve a few previously documented projects to show that have moved on a bit. Below you can see the rippled bowl, arched panels and one of the tattooed fists. The walnut bowl is finished and just needs to be photographed properly then delivered, I really like this variation with the ripples top and bottom and will be offering a very limited number for sale in future. The arched panels are primed and ready for final painting as can be seen in the second image. In addition both the tattooed fists have been installed on the clients stairs but still need a final sand and oil. The guys from Thomas Philpott Cabinet Makers did an amazing job installing them.

The images below show my latest prototype for another wooden bowl design. I had the idea for this shape when I was half-asleep one morning. This example was carved from some scrap Sapele. The finished bowl really is a lovely little object and will definitely see further development.

The three images below show some parts that will be used to line doorways in a clients house. The first images shows a hole being cut into walnut strips. These strips will have a molding shape cut into them and then the oak flower carvings shown in the second and third image will be inserted into these. Each doorway will have a different flower motif - 5 doorways, 8 flowers for each doorway. These intricate carvings had to be cut with a very small tapered ball nosed tool (1/16 inch tip) to get the detail.

In a similar vein the card suit carvings, cut in walnut, shown below also use a very small tool to get the detail. These are cut two sided with a 12mm circular plug on the back of them that will be inserted into holes to provide a decorative cover for screw locations.

The ceiling rose shown below was created to house 20 wires that will be stretched around a room with ornamental bulbs on them. To help evenly space the wires we went for a 10 sided design with scalloped edges. This will be painted to match the ceiling colour. This was also a two-sided cut, carving the cavity on the back first then the domed shape after. I also carved some small walnut plugs that will go in the screw holes around the edge once its painted.

The scalloped fan shape you can see in the images below looks relatively simple but its size pushed the CNC and tooling to the limit. The finished part is 100mm high - given I only have 150mm gantry height this meant having to be very careful with positioning of the tool and making sure the tool collet would not collide with the part when cutting. MY safe distance that the tool travels above the part when cutting was only 1.5mm over the surface. As you can see from the images it came out well and the final photo shows it installed waiting to be painted.

The final job to document today is the largest v-inlay I’ve done. The customers wanted a Celtic weave design carved in oak and inlayed into a walnut step. I drew my interpretation of the design in the software I use (Vectric Aspire) as you can see rendered in the first image. I decided to make it in oak and inlay walnut into it, then cut this out and inlay the whole disk into the step as a separate piece. This approach was down to its large size and not being sure how well the inlay process would work at this size. In the images you can see the oak part with the cavity carved out and the walnut insert. I make these so there is a 1.5mm gap underneath for glue and a minimum of 5mm of depth to create the glue joint. The parts are glued and clamped overnight then its run through the planer to get down to the correct inlay depth. As you can see in the final two images this came out perfectly. I am really looking forward to it being installed and oiled as it should look incredible.

Arched Doorway, Fountains Abbey, Moulding, Light Covers, an Old Bowl etc.

It’s been a busy couple of weeks in and out of the workshop recently. A lot of work has been for a long term job I’m doing in collaboration with Thomas Philpott Cabinet Makers (the guys downstairs in the workshop) for a client who is completely remodelling their home with some very interesting and ornate features.

One recent set of components that were required for this was a set of panels to go on the underside of an arched doorway. We scratched our heads a bit about how to do these but in the end went for bending sheets of 3mm MDF into a curved glued form and machining the beaded, raised panel shape into these to match the rest of the panelling in the room which is being painted.

In the set of photos shown below you can see this process documented. The first few images show the forms used to curve the MDF and also to cradle it once curved on the CNC. The fourth image shows the MDF glued and in the vacuum bag to keep it in position overnight while the glue set. In the fifth image you can see the formed panel, which was sawn into three pieces. The cradle was then positioned onto the CNC and I machined out a precise curve to ensure everything would line up perfectly.

Each panel was screwed in place on the cradle and then the panel shape carved into it and the edges squared up. The finished parts can be seen in the last image, I also made a saw jig for these so they could be cut to length for installation. They have now been installed but I have not been able to get to the clients house yet to take a photo but will update when I can.

Last weekend we got away for the weekend to one of my favourite places in the UK; Fountains Abbey. Below you can see a photo of the ruin of the 12th century abbey - its location in a secluded valley is unusual for such a large building but just adds to the magic. Inside the ruin the light and shapes are amazing, we were particularly lucky to have a nice sunny autumn day to accent this as can be seen in the second image below. The last image is a carving that was on the wall in the more recent hall that was built near the ruin. It’s a very good carving, almost certainly Lime wood and in the style of Grinling Gibbons although not quite the same quality as the master, impressive nonetheless. Visiting places like this is one of the ways I get inspired and motivated to create my own work… If your in North Yorkshire its highly recommended.

The Moulding toolpath is a really good featured that was added to Vectric’s Aspire software about 2 years ago. It allows you to machine standard cross sections very efficiently. I’ve had need for it twice in the last two weeks. The first was to cut arched pieces of architrave to match the moulding being used, as seen in the first three pictures below. The second was to create a curved pieces of cornice to match another much deeper moulding (65mm). The process for both of these was to measure the original carefully using digital calipers, draw the profile in the software and then cut a 2D sample to compare to the original and make any small adjustments. Then you can literally extrude this shape to make a moulding toolpath to carve the shape. As you can see in the last photo you can get this pretty much perfect and they are also pretty efficient to cut too.

A while back I cut a prototype for a light cover for a client, they approved it but did not want all the parts cutting until the lights were ready for install. I got the go-ahead with these last week so went into production mode carving 10 of them at once - 2 sided. There was a bit of tear-out in the oak on a couple of them so I had to cut a couple more, adjusting the toolpath to minimise the chance for this to happen. These are waiting for final finish before install. The pictures below show them in process but not the complete set (I forgot to take a photo)…

When I first started CeorfanWorks I made a bowl in Sapele with a rippled back. I really liked the design and had always intended to make a second version the original sits on the piano at home. A recent visitor saw the original and really liked it, he’s now commissioned me to make him one in Walnut. The thing I loved about the original was the rippled shape and how it interacts with the grain, the only problem is with it being on the underside its quite hidden - hence we have the original on the piano where its elevated. For this version I added some ripples to the top as well (although not as pronounced) which looks really good. Below you can see the process for cutting the bowl (two sided). This now needs sanding to eliminate all the tooling marks (although these are light I like to try and get rid of them all) and then I’ll oil it which should really make the grain pop.

Finally a few other quick jobs from the shop (it has been busy). I made some internal panels for a window frame I cut the parts for a few weeks ago (first image below). Another job was a couple of curved components which I don’t actually know the use of (I just draw them to spec and cut them…). The last image shows the result of my new branding iron I ordered which I can use to burn the logo into products rather than always carve it - the carving takes time and can be awkward to finish. I had a bit of trouble with heating it and making a good mark but with some practice I’m sure I’ll get good results.

Loose Ends, Decorative Beam Carvings and 2D Components

To finish up some business from the last blog entry you can see in the first picture below the fully painted Mayan Pyramid my son and I made for his school project. The teacher was very happy with it but more important we really had fun making it and I think he learned a few things (I know I did)…

The second image below shows some bought parts that let wires come up through a hole in a desk. The guys in the workshop had lost one of the tops so I made a new one (the one on the right) for them. Really nice to quickly be able to make a simple component without having to wait for it to be ordered.

The third image on the top row shows a 2.4m (8 ft.) board, being carved by the CNC. To carve parts this long I have to pull them through the 900mm bed carefully locating them to ensure they are straight and indexed in the right place. I have good method for this now using a jig to keep it straight and a known tool position to locate its length correctly. The design shown in the image uses a combination of V-Carving toolpaths with a flat bottom pocket and also the fluting toolpath for the swept shapes in between - this is relatively quick to machine but still take a while when you need 6 metres of it. To secure this under the beam where it will be installed I cut 10 mm holes for the screw to sit within. To cover these I carved some decorative square-domed walnut plugs which you can see in the second row of photos. The first one shows the back with the 10 mm circle that will insert into the hole. Once this side is cut then are flipped over, aligned accurately using dowels and the top dome shape carved with a small ball-nosed tool. I left tabs to hold them in place and then trimmed these off with a knife and sanded them clean on a disk sander. You can see the finished parts in the photo below with the metal ruler. These small accurate pieces are very satisfying to make and turn a negative (the screw hole) into a decorative positive addition to the design.

The beam that the long carving shown above is going onto the base of also has decorative sides. Running along the length will be arches. Each one is made from the components shown in the first three photos in block below. These will have a 4mm wide walnut bead glued into the centre and then be sawn using the MDF jigs you can see in the middle photo. These will go together make the joint to complete the arch.

The top part of the beam will include a decorative moulding that will have an egg and dart element inserted to it. A lot of this last week has been spent carving lengths of this as you can see in the bottom three images. These have to be indexed through and aligned as accurately as possible. You can normally see a slight witness line where they overlap but this is easily sanded out. I still have about 5 metres of this left to carve. Each metre takes about 3 hours to cut using a tool with a 1.5mm (1/16”) tip diameter to get the fine detail…

Finally the guys in the workshop needed some 2D parts cutting which they can make by hand but the CNC can do more accurately and quickly. The first of these was some dividers cut out of 15mm thick maple wood. These had to interlock to create the grid to go in the drawers. I used the T-Bone fillet option in the Vectric software to allow the joint to fit properly as you can see in the middle-top photo below. The final photo shows the parts waiting a finish sand and final assembly.

The last three images show some long MDF parts required for a small rise of stairs that had to fit round some existing newel posts at a customers house. Again I needed to index these through the machine as the boards were 1500mm long but everything came out well and the guys were very pleased with how easy these were to assemble. You can see the finished set of stairs waiting for install in the final image.

Tattooed Wooden Fists, Door Update, Samples, Plywood Desk and a Mayan Pyramid

Tattooed Fists

Out of necessity I’ve been learning how to tattoo for the last couple of weeks. In particular to transcribe the tattoo of my client onto the wooden arms/fists I made. This proved to be a challenge (to say the least). I started by drawing a couple of flat versions of the tattoo on paper based on the photos of the clients arm, this was to figure out how everything lined up as the tribal patter went around his arm and ultimately proved invaluable. Then I pencilled the design onto one of the arms. This again took a while and multiple erasings to get things spaced correctly and working right. Once the pencil version looked OK I started the pyrography. This uses pen with a heated metal nib to literally burn the design into the wood. If you make a mistake then you have to sand it off… so I proceeded to carefully outline the main black areas. Next I filled the solid areas and then added the outline and finally the detail. Once the first one was finished I used that to help me do the second so this was quicker but still time consuming (approx. 4/5 days to do all the work for both arms). The various stages can be seen in the images below. I was very happy with how these turned out and the finished result exceeded my expectations of how good this concept would look. The customer will be seeing them in person today, I hope he likes them as much as I do…

Door Update

The door I have been working on was put into its frame, sanded and a walnut inlay added around the inside of the rails and stiles. We also placed the walnut beads I made to hold the glass in place and put a coat of oil on it. This now just needs sanding back, more oil and the glass putting in place. The walnut really accents the panel well and I love the way the grain of the oak looks on the scalloped areas.


Below you can see a few random items I’ve been slotting in the past couple of weeks. The first is a new design for the magnetic key-holder. I like how this looks but don’t think the oak works for it so will probably stick to maple like the first one I built. The second image is a small sign I made to put next to my display at the Vectric User Group that I attended on Wednesday. It was good to see the new features going into the software and catch up with some old friends there. The final image is some egg and dart I modelled and machined based on a photo supplied by the customer. This was a machining test to see how it looked and time how long it takes to make so I can give him an accurate price on carving 12 metres of it!

Plywood Desk

My son needed a desk for his room. It had to fit over a box surrounding some pipes and also fulfil his wish list of having shelves, a tilted drawing board and looking “cool”… I volunteered to make it and ended up creating a design to use up some sheets of 12mm plywood I had in the workshop. Originally I designed it with plywood legs but a mistake on my behalf, running the same file twice instead of making the left and right meant I ran out of material (doh!). Some hasty design changes and adjustment meant I could still complete it without buying more material, but I did need to source some metal legs to add on instead. The whole thing took me about 50% longer than it should have to make as tends to be the case. This but does the job and most importantly the customer was very happy with it… You can see some of the parts being cut below (it all slotted together straight off the machine) and the desk with and without the drawing board in place…

Mayan Pyramid

The last thing I worked on (literally this morning) was also for my son. His homework this week was to draw and describe a Mayan Temple - they also said if he wanted he could make a model of one too. I thought this would be a fun thing to work on together so I can show him the CAD/CAM process and something cutting on the CNC. We designed some files to cut into 18mm MDF that would stack up on each other to make the pyramid and also the steps going down each of the sides. You can see a willing helper vacuuming and sanding in the first two images and the finished pieces stacked up and glued in the third. Following this we scraped away the excess glue and put sanding sealer on it so it can be sanded back and painted tomorrow. It was really good fun and some “stealth” education to work on it together and we were both pretty pleased with how it turned out…
